336LED Running Water COB Strip Light
•Running water COB strip light with high density of LEDs
•Linear lighting, without light spot
•High temperature resistance, long lifespan
•No bracket, flexible COB strip light with good bending performance, seamless butting between two solder points
•IC built on the FPC board
•Supporting multiply running water effects
•Running water controller and remoter are recommended.
| Model NO. | SC-LCOBX-336-12W-24V-12F0 | ||||||||||||
| Product Description | |||||||||||||
| Product Feature: | •Running water COB strip light with high density of LEDs •Linear lighting, without light spot •High temperature resistance, long lifespan •No bracket, flexible COB strip light with good bending performance, seamless butting between two solder points •IC built on the FPC board •Supporting multiply running water effects •Running water controller and remoter are recommended. |
||||||||||||
| Product Specification: All data are based on 1 meter IP20 strip | |||||||||||||
| Product No. | LED Qty | Voltage | Power | SDCM | Ra | CCT | Luminous | Luminance | Beam | PCB Layer | Width | Min. | |
| Efficacy | Flux | Angle | Cutting | ||||||||||
| SC-LCOB30-336-11W-24V-12F0-80 | 336 | 24V | 11W | <3 | 80 | 3000K | 90- | 1000- | 140° | Double | 12mm | 125mm | |
| 100lm/W | 1100lm | Copper | |||||||||||
| SC-LCOB40-336-11W-24V-12F0-80 | 336 | 24V | 11W | <3 | 80 | 4000K | 140° | Double | 12mm | 125mm | |||
| Copper | |||||||||||||
| SC-LCOB65-336-11W-24V-12F0-80 | 336 | 24V | 11W | <3 | 80 | 6500K | 140° | Double | 12mm | 125mm | |||
| Copper | |||||||||||||
| Dimension Drawing: | 24V |  |
|||||||||||
| Available Waterproof Grade: | IP20, IP65 | ||||||||||||
Need this product for your project?
Share your application, voltage, length, IP rating and quantity. We will respond with a practical recommendation or sample option.
