IP68 Waterproof COB Strip Light
•High density COB LEDs
•Linear lighting, without light spot, soft and uniform luminance
•High CRI, high brightness and high efficiency
•High temperature resistance, long lifespan
•No bracket, better bending performance, seamless butting between two solder points
•Food grade enviroment friendly silicone extrusion, anti-UV, anti-acid, anti-alkali
•IP68 waterproof grade with excellent waterproof performance.
| Model NO. | SC-LCOBX-480-12W-24V-08F5 | ||||||||||||
| Product Description | |||||||||||||
| Product Feature: | •High density COB LEDs •Linear lighting, without light spot, soft and uniform luminance •High CRI, high brightness and high efficiency •High temperature resistance, long lifespan •No bracket, better bending performance, seamless butting between two solder points •Food grade enviroment friendly silicone extrusion, anti-UV, anti-acid, anti-alkali •IP68 waterproof grade with excellent waterproof performance. |
||||||||||||
| Product Specification: All data are based on 1 meter IP68 strip | |||||||||||||
| Product No. | LED Qty | Voltage | Power | SDCM | Ra | CCT | Luminous | Luminance | Beam | PCB Layer | Width | Min. | |
| Efficacy | Flux | Angle | Cutting | ||||||||||
| SC-LCOB30-480-12W-24V-08F5-90 | 480 | 24V | 12W | ≤3 | 90 | 3000K | / | / | 140° | Double | 8mm | 50mm | |
| Copper | |||||||||||||
| SC-LCOB40-480-12W-24V-08F5-90 | 480 | 24V | 12W | ≤3 | 90 | 4000K | / | / | 140° | Double | 8mm | 50mm | |
| Copper | |||||||||||||
| SC-LCOB65-480-12W-24V-08F5-90 | 480 | 24V | 12W | ≤3 | 90 | 6500K | / | / | 140° | Double | 8mm | 50mm | |
| Copper | |||||||||||||
| Dimension Drawing: | 24V |  |
|||||||||||
Need this product for your project?
Share your application, voltage, length, IP rating and quantity. We will respond with a practical recommendation or sample option.
