480LED 8mm width COB Strip Light
•High density COB LEDs
•Linear lighting, without light spot, soft and uniform luminance
•High brightness and high efficiency
•Full spectrum LED strip with excellent color rendering effect, CRI>98
•Reach ERP energy efficiency F class
•High temperature resistance, long lifespan
•No bracket, flexible COB strip light with better bending performance, seamless butting between two solder points
| Model NO. | SC-LCOBX-480-12W-12/24V-08F0-98 | ||||||||||||
| Product Description | |||||||||||||
| Product Feature: | •High density COB LEDs •Linear lighting, without light spot, soft and uniform luminance •High brightness and high efficiency •Full spectrum LED strip with excellent color rendering effect, CRI>98 •Reach ERP energy efficiency F class •High temperature resistance, long lifespan •No bracket, flexible COB strip light with better bending performance, seamless butting between two solder points |
||||||||||||
| Product Specification: All data are based on 1 meter IP20 strip | |||||||||||||
| Product No. | LED Qty | Voltage | Power | SDCM | Ra | CCT | Luminous | Luminance | Beam | PCB Layer | Width | Min. | |
| Efficacy | Flux | Angle | Cutting | ||||||||||
| SC-LCOB30-480-12W-12V-08F0-98 | 480 | 12V | 12W | ≤3 | ≥98 | 3000K | 80lm/W | 960lm | 140° | Double | 8mm | 25mm | |
| Copper | |||||||||||||
| SC-LCOB40-480-12W-12V-08F0-98 | 480 | 12V | 12W | ≤3 | ≥98 | 4000K | 90lm/W | 1080lm | 140° | Double | 8mm | 25mm | |
| Copper | |||||||||||||
| SC-LCOB65-480-12W-12V-08F0-98 | 480 | 12V | 12W | ≤3 | ≥98 | 6500K | 100lm/W | 1200lm | 140° | Double | 8mm | 25mm | |
| Copper | |||||||||||||
| SC-LCOB30-480-12W-24V-08F0-98 | 480 | 24V | 12W | ≤3 | ≥98 | 3000K | 80lm/W | 960lm | 140° | Double | 8mm | 50mm | |
| Copper | |||||||||||||
| SC-LCOB40-480-12W-24V-08F0-98 | 480 | 24V | 12W | ≤3 | ≥98 | 4000K | 90lm/W | 1080lm | 140° | Double | 8mm | 50mm | |
| Copper | |||||||||||||
| SC-LCOB65-480-12W-24V-08F0-98 | 480 | 24V | 12W | ≤3 | ≥98 | 6500K | 100lm/W | 1200lm | 140° | Double | 8mm | 50mm | |
| Copper | |||||||||||||
| Dimension Drawing: | 12V |  |
|||||||||||
| 24V |  |
||||||||||||
| Available Waterproof Grade: | IP20, IP65, IP67, IP68 | ||||||||||||
